Smart roller – filter that will take care of the water in the aquarium so it’s crystal clear. Compact, very
efficient, created specifically for marine aquariums. Highly efficient roller. With Smart technology, you can
easily determine how often the material should wind. Easy roll replacement. Special high-quality roller
material, which, thanks to its properties, will take care of the cleanliness of the water and maintain the
right parameters.
The certified non-woven material removes larger particles of impurities from the water, but neither
completely removes trace elements, nor NO3 and PO4, which are essential in marine aquaristics. It
works perfectly with protein skimmers. Because the roll is 20 cm (7.87 inch) wide and as much as 40 m
(1574.8 inch) long, it lasts longer than the competitive devices.
Key features:
● High performance – up to 3 months of continuous operation
● Easy plug & play installation
● Special high quality material to keep water crystal clear and maintain parameters
● Smart functionality (management from the Smart Reef app, and soon also access through the
Social Reef app)
● Integrated media basket
● Easy roll replacement
● Roll dimensions – width: 20 cm (7.87 inch), length: 40 m (1574.8 inch)
● Connection for 40 mm (1.57 inch) tubing
● Individually adjustable flow rate – maximum 11000 L/hour
● Recommended aquarium size from 300-1500 L
All you need to control is the free Smart Reef app, which you can install on your phone (Android, IOS) or
operate from your browser. Simply pair the Smart roller M with your account on the app to enjoy a range
of Smart functionalities:
Smart functionalities:
● free user-friendly Smart Reef app for Android, IOS or computer (browser-based operation)
● creation and modification of a flexible dosing schedule
● information on how long the roll is enough
● setting the rate of scrolling
● alerts when the roll is blocked
● delayed start settings
Additional features:
● simple setup and easy service
● small size allows use even in small sumps
● modern design
● height-adjustable legs and hanging option
● drain equipped with an element for additional filtration media
TECHNICAL SPECIFICATIONS
Dimensions and weight of the device:
width 37,5 cm / 15 inch
height 48 cm / 19 inch
depth 12 cm / 4.6 inch
weight 3,12 kg
Media space in the basket:
9 cm x 14,8 cm x 4,6 cm / 3.5 in x 6 in x 2 in
Wymiary i waga opakowania:
width 28 cm / 11 inch
height 52,5 cm / 21 inch
depth 22 cm / 8.7 inch
weight 3,66 kg
Power supply specification:
Power supply voltage 100-230 VAC 50/60 Hz (AC-DC adapter included)
Power consumption 0,5-5 W max
The devices are CE certified
Kit contents:
● device
● Smart roller M Replacement mat
● basket
● offset
● Liquid level sensor (50 cm / 20 inch)
● hanger
● sensor holder
● closing the drain
● spare empty roll fixture
● Flat knob 5×25 mm / 0.2 x 0.1 inch
● instruction manual
● power supply
● Neodymium magnet for resetting the device
