High-Performance Refrigeration Technology
- TK Heat Pumps use internationally-recognized rotary compressors with a titanium coaxial heat exchangers to ensure low-energy consumption while sustaining the highest in performance thoroughput. The technology in these heat pumps allows one to decrease noise levels and achieve a high COP (coefficient of performance) contributing to significant energy savings.
Digital Thermostat
- The setting of functions is intuitive and the temperature detection is accurate, resolution 0,5°C (1°F). The setting range is 5°C – 40°C (32 – 104 °F) and there is a closed loop temperature control system with high accuracy and extremely tight differential 2 °C/ 5 °F. Displayed temperature is in °C or °F and there are security alarms. Possibility to monitor the chiller even remotely, degree of protection IP24.
Efficient Design
- The unit is characterized by a solid structure and was designed to provide maximum oxidation protection—great for use with salt-water.
Unique Feature
- These units are also suitable for industrial applications and outdoor installation.Vertical ventilation ensures optimal operation even when operated in harsh environments.
Technical Details
| Supply |  |
400V – 50Hz 3ph e 230V – 60Hz 1ph |
| Power Consumption | |
4350 w |
| Cooling Power | |
8,7 kw |
| Ecological Gas | |
R410A |
| Min. Flow Rate | |
4500 lt / h |
| Dimensions | |
mm. 816 x 690 x 850 (h) |
| Dimensions | |
in. 32.13 x 27.17 x 33.46 (h) |
| Weight | |
105 kg |
| Connections | |
fitting 1/2″ – 56mm int. Tube diameter |
